twin shaft metal shredder for waste metal aluminum scrap recycling
Metal and aluminum scrap double shaft shredding machine
Double Shaft Shredders is featured sophisticated design, robust structure, and high efficient shredding result, two shaft shredders are normally used first stage shredder for materials like aluminum scrap, steel drums, stainless steel plate and copper materials, With a double shaft shredder, once the materials is fed into the cutting chamber, the cutting blades with hooks will grab material and then shear it down to strips.
The shreds are directly discharged after cutting without passing through a screen, so the size of shreds is quite random, custom blade widths can match your required sizing. Programmed Reveres rotation of the rotor shaft can prevent damages when overload.
Both electrical and hydraulic drive systems available.
Specially design for shredding metal scrap and metal plate meterials, such as stainless steel scrap，aluminum scrap and other metal scrap.
*Dual-shaft/dual-rotor design with differential shaft speeds
- *Heavy duty internal gearbox
- *Custom blade widths to match your required sizing
- *High Alloy blades materials with optional hard-facing to increase cutting effectiveness
- *Recirculation systems for multi-pass processing if needed to meet required size reduction
- *Choice of drive system (hydraulic or electric)
Dimension L/W/H (mm)
1210 X 1080 X 1840
2650 X 910 X 1910
3010 X 1372 X 1910
Cutting Chamber C/D （mm)
410 X 390
510 X 450
610 X 480
Rotor Diameter (mm)
Blade Quantity (pcs)
Blade Thickness (mm)
Main Motor Power (KW)
11 * 11
The size of shreds is quite random, custom blade widths can match your required sizing
