Industrial high security P7 paper shredding and crushing machine
Industrial high security P7 paper shredding and crushing machine
Industrial high security P7 paper shredding and crushing machine
Industrial high security P7 paper shredding and crushing machine
Model
SPP600 Plus

Review

Description

SUPU SPP600 Professional Paper Disintegratorsuitable for waste PaperDocumentBooksBanknotesID card, CD recycling and data destruction purposefinal particle by customized size for 2*2mm-15*15mm with 250-350 kg/hr working capacitySPP600 contain industrial shredding systemmagnetic separated system high speed crushing systemdust collection system and smart control PLC systemsatisfied with high security stand DIN66399 P5 –P7 level for any confidential paper destruction.

Advantages:

l  Paper/document shredder machine into powder

l  The higher the security requirements for the data destruction up to DIN 66399 P7

l  With magnetic iron separated system to remove the iron

l  Dust collector has the simple construction also can be used in a normal air volume range and dust cleaning is up to 99.9%,no secondary adsorption to the dust.

l  High Security level determinable through screen mesh diameter one machine satisfied with different shredded standard from 2*2mm to 15*15mm output particle

How to process


Feeding the paper into the feeding portoaper will shredded by the shredding systemat the same timemagnetic separated system will separated the iron from the shredded paperand discharge to the iron collect bin



Conveyor will carry the shredded paper to the high speed crushing system to crush itfinal output particle will through the screen mesh into the discharge bagdust collect system will process the high percentage dust and powder collection into the dust collect bin.

Technical Date:
Model
SPP600
Shredding Materials
Paper/Banknotes/ documents/ID card / Tape/ CD / Folder / Film/ PCB board
Security Level (DN 66399)
P-5 to P-7
Construction
High speed crushing
After Shred size
2.5* 2.5mm – 15*15mm
Throughout per hour
1) with shredding particle 3*3mm 250kg/hr     2)  with shredding particle 5*5mm more than 350 kg/hr
Shredding capacity per time for paper
Paper shredding capacity: 150 -200 sheets paper / Time
Bag size
960L800D* 1200H mm
Filter area
6* filters, each filter 320(D) *900(H)mm
Power/ Voltage / Frequency
32 KW /( 3 phase, 380V/ 50HZ
Machine Size
7500L*4795W*3400 (H) mm
