Supu Heavy Duty Paper Shredder

SUPU PDS600 Heavy duty Paper shredder,suitable for waste Paper,Document,Books,Banknotes,recycling and destruction purpose,final particle size for 9mm* 40-80mm with more than 1.5 ton/hr working capacity,PDS600 contain high speed Shredding system,feeding and discharge conveyor, smart control PLC system.
 Shredding result

Paper,document,file,books,banknote,CD,Card etc
1. Two shaft shredding construction with speed control converyor
2. The frame is combinational structures, made from precision machined extra-thick sheet,slewing axis is forced, Lange-angle, hexagonal prism, , so good-sized material is practicable.
3. High level blade can easy to shred file with metal
4. PLC control system, forward and reverse operate and stop automatically can protect themachine when the materials is too big and much. Operate safely, low-speed running, lownoise, little dust.
5. With strong planetary gear box system to make the shredding power strong,improved the shredding effect.
Technical Date:
Crushable Materials
                      Shredder construction
 Two shaft shredder
Blade construction
                            High speed cross cut blade
                             Shredding capacity
500 sheet A4 paper with file
Shredding Particles
9mm * random or customized
Throughout per hour
1.5-3 ton per hour
Feeding width
600 mm
Power/ Voltage
18.5KW / 380V/ 50HZ
Machine Weight
2350 KGS
Machine size
           4766.6(L) x1730(w) x 1749.9(H) mm
